The commonly used power for dust removal fans is a three-phase 220 motor with a capacity of 3.5 amperes per kilowatt. Three hundred and eight motors are commonly used, with one kilowatt and two amperes. Low voltage 660 motor, 1.2 amperes per kilowatt. High voltage 3000 volt motor, four kilowatts per ampere. High voltage 6000 volts
1、 Parameters of dust removal fan:
1. Processed air volume: 100 cubic meters per minute
2. Dust removal efficiency of total dust: greater than
3. Dust removal efficiency for respiratory dust: greater than 90%
4. Liquid gas ratio: less than 0.2 liters per cubic meter
5. Moisture content of exhaust gas: less than 0.01 liters per cubic meter
6. Rated working resistance: less than 300 Pa
7. Model of electric motor: YBF2-132S-4
8. Rated power: 5.5 kilowatts
Rated current of 9.380/660V: 11.6A/6.7A
Rated current of 10.660/1140V: 6.7A/3.9A
11. Rated speed: 1440 revolutions per minute
12. Type: Explosion proof type
13. Logo: Exd Ⅰ
14. Method of work: Continuous work system
15. Suitable dust types: Some hydrophilic dust, such as coal, rock, cement, etc
16. Dimensions of the appearance: length 2030mm, width 710mm, height 1050mm
17. Total weight: 398 kilograms
